oscillating knife cut 15mm corrugated papers, white board, EVA,
cardboard, fast speed, stable quality, long working life
Productivity
The new DCZ 7 Series machines provide fast and flexible solutions
to prototyping and short run production requirements. Automating
your finishing department increases productivity and reduces
bottlenecks, this is clear to see. With the ability to prototype,
the DCZ 7 Series machine also allows your design team to be more
creative.
Flexibility
The high speed, high accuracy digital servo drives provide smooth
and reliable operation Versatile tooling options ensure that you
have the ability to finish a vast range of materials quickly and
easily. Adding extra tooling, such as the powerful 1KW router,
extends the range of materials that can be cut far beyond those
that a single point knife cutting system can handle. Because tables
come in an extensive range of sizes you can be confident of finding
a solution that fits your requirements perfectly.
Tooling
The DCZ 7 Series tool head comprises 2 interchangeable,
tangentially driven tool modules and a Pen, incorporating the
following, standard set of tools.
- Electronic Oscillating Knife – with variable oscillating control,
max 12,000rpm. Suitable for cutting a variety of materials, up to
15mm in thickness.
- Drag Knife – With a selection of blade types and angles to suit
most materials Creasing Tool – with interchangeable creasing
profiles. Suitable for creasing a variety of both fluted and
non-fluted packaging materials.
- Pen Tool – Suitable for drawing on a variety of materials
- Optional Router – with variable spindle control, speed max
50,000rpm Suitable for harder materials e.g. Acrylic, Plexiglas,
wood and thin Aluminium. This tool is not part of the standard
configuration but can be retrofitted if required.
Camera Registration
The video camera registration module fitted to the DCZ 7 Series
gives you perfect cut to print registration every time. It
minimizes the setup time on the machine, increases productivity and
virtually eliminates errors and subsequent wastage. The module
comprises a color video camera plus dedicated software which
utilizes any style of registration mark.
How to place an order:
1. After confirming order details, we will make Proforma Invoice
for you.
2. After receiving 30% deposite will start test machine carefully.
Ensure the excellent performance.
3. After tested the machine, will pack and send out.
4. When you received the printer, there is user manual and video to
guide you install,operate and maintain.
5. When any technical issues, you can contact with our technician
directly. They will help you solve the problem by Skype or
Teamviewer. So you can rest assured about the after service.
6. We provide free training in our factory. When order several
sets, can also send technician to your place. Help set up machine,
and provide training to your staffs.
Look forward to cooperate with you, be successful with us!
Specification:
| Model | DCZ762516 | DCZ761713 | DCZ761310 | | Effective cutting area | 2500*1600mm | 1700*1300mm | 1300*1000mm | | Configuration | Oscillating knife,pen,creasing tool,drag knife, foam tool, v cut
tool | | Max aped | 1400mm/s | | Smallest cutting diameter | 6mm | | Maximum cutting thickness | 60mm | | Control line and driver | Servo | | Precision | ≤0.1mm | | Data form | HPGL,DXF,PDF | | Voltage | 220v±10%50Hz | | Data port | parallel port,serial port,USB port | | Option | Video registration system | | Occupy dimension(L*W*H) | 3500*3200*1400mm | 2700*2900*1400mm | 2300*2600*1400mm | | Note | Other size can be customized |
|
|
Cutting Samples:
Video registration system
