corrugated box sample making machine,die cut, UV print cut, laser
light, 60mm cut, Panosonic motor, vibration
description
It comes from the American High-end four Axis high speed motion
control system.
Global unique intelligent deviation correction system
The only automatic maintenance system in the industry
The first remote diagnosis system
Many tools can be replaced arbitrarily. The operations are simple
and convenient and the cutting range is wider.
The distinctive MAKE CCD free positioning function, without gauge
point but still realizes precise localization
The first set of longmen double-drive cutting system in the
industry makes the operation more stable
The first set of mute cutting system in the industry makes the work
environment more pleased.
| Cutting material | foam, PVC, corrugated board, styrene, Coroplast, Celtec, magnetic
film, adhesive vinyl, leather, rubber, fabrics, high intensity
reflective films, paper, cardboard, polystyrene, magnetic films,
vinyl, leather, fabrics, paper, etc |
| Application | Used in corrugated, carton and paper packaging line, etc |
| Operation properties | The computer operation is simultaneously conducted with the cutting
table, fulfilling the data transmission rapidly. It can be
continuously used. |
| Max Speed | 1500mm/s |
| Smallest Cutting Diameter | 6mm |
| Max Cutting & Creasing Thickness | 60 mm |
| Overlapping Precision | <0.1mm |
| Vacuum Pump | 5.5KW(220v three-phase or 380v three-phase) |
| Control Line and Driver | Servo motor |
| Data form | DXF,HPGL |
| Voltage | 220v±10%50HZ |
| Data Port | Ethernet port. |
| Type of controlled | Importing 4 Axis Controller |
| Safety device | It applies infrared ray induction, the reaction is sensitive. Safe
and reliable |
.
Easy to use
· our M-70 tables are easy to install and simple to set-up and use.
The table is programmed for use with our own software, which apart
from the manual adjustment for the depth of the knife, will reduce
the need for hands-on setup of the table.
2. Saves time and money whilst improving quality
· Eliminates the cost and time you spend cutting paper patterns and
making brass bound pattern boards.
· Greatly reduces the time taken to hand cut sample and graded
paper patterns.
· Consistent accuracy throughout, utilizing the our own software,
any modifications to the pattern can be re-cut quickly and
efficiently.
· Reduces your lead times for samples, short production runs and
overall pattern development time for both sampling and production,
helping you to provide that 'quick response' your customer demands.
INNOVATIVE FEATURES
1.Our cutting machines use imported American CPU and precise
eletronic components, meeting world leading level in terms of
machines stability and operability.
2.Self developed built in CNC control system.
3.File format can be DXF, PLT and any CAD software with HPGL format
4.8 groups of knives and pen arrangement provides cutting solution
for different material with different thickness
5.our cutting machines equipped with imported linear guiderail,
famous driving motors. It is fast, accurate, smooth.
