corrugated paper sample box cutting machine for package and priNT
The machines have the machines have three types of functional
heads: vibration cutting head, creasing wheels, V-Cutter, high
speed milling Router, with drawing pen. It enable the machine can
work on different materials; corrugated paper, gray board, white
cardboard, plastic sheets, composite materials, textiles, leathers,
foam board, sponge etc at option of 15mm maximum cutting height.
| Operation properties | Computer operation and cutting machines can be used simultaneously
for quick data transmission capable of continuous operations |
| Cutting speed | Maxi 1500mm/s |
| Cutting Thickness | 0.5-15mm |
| Cut materials | Ivory cardboard,gray paper,corrugated paper,plastic sheets,
composite materials and leather materials, rubber,Plastic corrugated sponge and foam board. |
| Number of pens | 8 different groups of strokes,half blades,full blades and pressure
wheel setup, Drawing pen |
| Positioning device | Red Ultra-Light / CCD camera head positioning |
| Method for fixing paper | Vacuum absorption |
| Cutting tolerance | ±0.2mm |
| Repeat accuracy | 0.05mm |
| Minimum circle | 5mm diameter |
| Transmission interface | Ethernet port |
| Format compatible | Compatibility format AI software,Auto cad,Coraldraw and all box software |
| Direcive system | HP-GL and GP-GL |
| Digital control panel | Liquid crystal display and contact button |
| Transmission materials | Straight-line guide rails and imported synchronous belts |
| Supply voltage | AC 220V 380V ±10%,50HZ |
| Vibration blade | Vibration cutter head motor at 25000rpm |
The Tools and Functions of Carton Box Cutting Machine:
1. Oscillating knife
It is fast, accurate and no burning nor smell.
2. Creasing wheel:
A set of creasing wheel with four different sizes can make good
folding lines according to your different materials.
3. 45 degree cutting knife
This is special for V groove making when it comes to materials like
honeycomb board, gray board and other relatively thicker materials.
4. Milling knife
This is specialized for Acrylic and thin wood material cutting.
5.CCD: camera, professional for positioning for print materials.
Automatic and precise.
